4.3 inch 480×272 tft lcd screen panel
This 4.3 inch 480×272 tft lcd screen panel product is our standard product for the medical field. It has passed various certification tests of medical treatment. It has strong anti-jamming performance. It can match our 4.3 inch standard projected capacitive touch panel . We have TN and IPS material display screens to choose from. Both general brightness and high-brightness schemes are available. Air-bonding and optical-bonding process can be selected according to the actual needs of cust... -
15.6 inch 1080P industrial tft lcd screen panel
Product Description Model Number HSD156JUW2-A10 Brand Grahowlet Size 15.6 inch Operating Temperature -35 to +85°C Storage Temperature -40 to +90 °C Outline Dimension 363.7(W)×215.7(H)x12.0(D) mm Active Area 344.16(W)×193.59(H) mm Dot pitch(mm) 0.2715 (H)x 0.2715(V) mm Surface treatment Hard coating Display Mode Normally Black,Transmissive,IPS Panel Color Depth 16.7M Contrast Ratio 1000:1 (Typ.) Response Time (ms) 15/15 (Max.)(Tr+Td) Backlight WLED Resolution... -
5 inch 800×480 tft lcd display with 50PINS RGB
Product Description Model Number HX050NL37-50ND-12A Brand Grahowlet Size 5.0 inch Operating Temperature -20℃ ～ 70℃ Storage Temperature -30℃ ～ 80℃ Outline Dimension 120.70(W) × 76.30(H) × 2.80(D) mm Active Area 108.00(W) × 64.80(H) mm Dot pitch(mm) 0.045(W) ×0.135(H) mm Surface treatment Anti-Glare Display Mode Normally White, Transmissive IPS Color Depth 16.7M Contrast Ratio 800:1 (Typ) Response Time (ms) 25ms (OFF+ON TYP) Backlight WLED Resolution 800... -
IPS lcd panel 10.1 inch 1280×800 tft lcd display module
Product Description Model Number HX101IA01D-40A Brand Grahowlet Size 10.1 inch Operating Temperature -20℃ ～ 70℃ Storage Temperature -30℃ ～ 80℃ Outline Dimension 229.46mm(W) ×149.10mm(H) ×4.80 mm(D) Active Area 216.96(W) × 135.60(H) mm Dot pitch(mm) 0.0565(W) × 0.1695(H) mm Surface treatment Anti-Glare Display Mode Normally Black, Transmissive,IPS Color Depth 16.7M Contrast Ratio 800:1 (Typ) Response Time (ms) 25ms (OFF+ON TYP) Backlight WLED Resolution 12... -
TN LCD Panel 7 inch tft lcd screen display with LVDS interface
Product Description Model Number HX070BL12-40NF-30A Brand Grahowlet Size 7.0 inch Operating Temperature -20℃ ～ 70℃ Storage Temperature -30℃ ～ 80℃ Outline Dimension 165.00mm(W)×100.00mm(H)×5.70mm(D) Active Area 154.2144(W) × 85.92(H) mm Dot pitch(mm) 0.1506(W) × 0.1432(H) mm Display Mode Normally Black, Transmissive TN Color Depth 16.7M Contrast Ratio 800:1 (Typ) Response Time (ms) 16ms (OFF+ON TYP) Backlight WLED Resolution 1024×600 Interface Type LVDS... -
800×600 8 inch lcd display panel with RGB interface
Product Description Model Number HX080NA-05A Brand Grahowlet Size 8.0 inch Operating Temperature -20℃ ～ 70℃ Storage Temperature -30℃ ～ 80℃ Outline Dimension 183.0(W) × 141.0(H)×6.00mm(D) Active Area 162.0(W) × 121.5(H) mm Dot pitch(mm) 0.0675(W) × 0.2025(H) mm Surface treatment Anti-Glare Display Mode Normally Black, Transmissive TN Color Depth 16.7M Contrast Ratio 800:1 (Typ) Response Time (ms) 25ms (OFF+ON TYP) Backlight WLED Resolution 800×600 In... -
IPS LCD panel 7 inch 1024×600 tft lcd screen
Customized Solution Grahowlet- China P-CAP & TFT Manufacturer • PCAP size from 1.3”-65” • PCAP & LCD module size: 1.3”-32” • Optical Bonding service : 1.3”-21.5” • HDMI & VGA T-CON Board available • IIC-USB interface Bridge board available •CTP can be Customized with cover glass surface treatment process AG(anti-glare), AR(anti-reflective), AF(anti-fingerprint) • Support touch with 12mm cover glass. • Support touch with pool of water. • Support touch with 5mm gloves. • Custom High...
