| Model Number |
HX0801845-PCAP |
| Brand |
Grahowlet |
| Size |
8.0 inch |
| Interface Type |
IIC/USB |
| Structure |
Glass+Glass |
| Controller IC |
Cypress |
| Touch Points |
10 points |
| Transparency |
≥85% |
| Surface Hardness |
≥6H |
| Operating Environment |
-20℃ ～ 70℃,≤85% RH |
| Storage Environment |
-30℃ ～ 80℃,≤85% RH |
| Power Supply Voltage |
2.8V ～ 3.3V |
| Outline Dimension |
193.00(W)x151.00(H)x2.00(D) mm |
| Viewing Area |
162.85(W)x122.34(H) mm |
| Support Systems |
Windows/Android/Linux etc. |
| Warranty |
1 year |
