7 inch industrial PCAP touch panel

7 inch industrial PCAP touch panel

Short Description:

     The 7 inch industrial PCAP touch panel with cytma568 touch controller ic, support operation with gloves, water , and working well with 10mm thick tempered glass or thick PC on top of the cover glass, mainly used in medical, industrial, security, home appliances and other fields. Deep custom service available.      The 7 inch industrial PCAP touch panel is our standard product. It has strong anti-jamming performance. It can match the applications of all 7-inch brands display with 800*480/...


  • Min.Order Quantity: 1 Piece/Pieces ( just for sample order )
  • Supply chain: at least 3~5 years
  • Payments: VISA,Pay Latre,L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal/cash payments etc.
  • Shipping: Support Express/Sea freight/Land freight/Air freight
  • Customization: Customized Shape/logo/packaging, etc
  • Product Detail

    Product Tags

         The 7 inch industrial PCAP touch panel with cytma568 touch controller ic, support operation with gloves, water , and working well with 10mm thick tempered glass or thick PC on top of the cover glass, mainly used in medical, industrial, security, home appliances and other fields. Deep custom service available.

         The 7 inch industrial PCAP touch panel is our standard product. It has strong anti-jamming performance. It can match the applications of all 7-inch brands display with 800*480/1024*600 resolution . We have TN and IPS material display screens to choose from. Both general brightness and high-brightness schemes are available. Air-bonding and optical-bonding process can be selected according to the actual needs of customer projects.

    TPM Specifications

    Model Number HX0701601 V2.0
    Brand Grahowlet
    Size 7.0 inch
    Interface Type IIC/USB
    Structure G+G
    Controller IC Cypress
    Touch Points 10 points
    Transparency ≥85%
    Surface Hardness ≥6H
    Operating Environment -20℃ ~ 70℃,≤85% RH
    Storage Environment -30℃ ~ 80℃,≤85% RH
    Power Supply Voltage 2.8V ~ 3.3V
    Outline Dimension 165.00(W)x100.00(H)x1.45(D) mm
    Viewing Area 154.88(W)x86.72(H) mm
    Support Systems Windows/Android/Linux etc.
    Warranty 1 year

    7 inch industrial PCAP touch panel - drawing
